A jointer creates a flat surface on wood, and yes, it can be used to correct bow and warp on one side of a board at a time. "A planer is a thicknesser. ... In other words, you put a board into the planer to make it thinner after you have already established one flat side using the jointer (or a hand plane.)

Do you really need a jointer?

Simply purchase your lumber already milled in S3S or S4S form (surfaced on three sides or surfaced on 4 sides). If you're at a point in your woodworking where you're starting to use rough sawn lumber, say from a lumber mill or your local sawyer, then a jointer is absolutely essential to your shop workflow.

What is the purpose of a wood jointer?

The jointer derives its name from its primary function of producing flat edges on boards prior to joining them edge-to-edge to produce wider boards. The use of this term probably arises from the name of a type of hand plane, the jointer plane, which is also used primarily for this purpose.

How important is a jointer in woodworking?

Rob Johnstone: Jointers are versatile and important tools for stock preparation and shaping. A jointer, properly set up and used, will allow you to create a dead straight edge on a piece of lumber … which makes for a good glue joint or a straightedge to rip from on your table saw.

What are the benefits of a jointer?

Here are some benefits you gain from running your lumber through a jointer.

• A jointer makes flattening surfaces and squaring edges quick and easy.
• With a jointer, you can remove all forms of defects (twists, wraps, cups, and bows) that can prevent your lumber from being flat or square.
• The jointer is fully adjustable.

What Does a Jointer Do? - Ask Matt #13

43 related questions found

What do joiners do?

A joiner works with timber to create a variety of structures integral to many buildings. This can include staircases, windows, doors, furniture and more. As a joiner, you will make and install these structures and fittings in the correct locations.

How large of a jointer do I need?

An 8-inch wide jointer allows me to joint wider boards than a 6-inch jointer, and 8-inch jointers usually come with longer infeed and outfeed beds, adding more support to the lumber. And 8-inch jointers are usually affordable enough for hobbyist woodworking shops.

Can you plane with a jointer?

It does exactly what a hand plane does, except that you move the wood across it instead of moving it across the wood. A jointer creates a flat surface on wood, and yes, it can be used to correct bow and warp on one side of a board at a time.

Do you use a jointer or planer first?

Most woodworkers know that you need both a planer and a jointer to get the most out of rough lumber (at least for power tool users). The jointer is used to flatten one face and square up one edge and the planer is then used to make the second face flat and parallel to the first.

Can you use a jointer on both sides?

You can't make both sides parallel by running both sides across the jointer. Your process is correct. If I'm doing a panel glue up I joint both edges, but I joint the second side after it has been ripped parallel.

When using the jointer you should stand?

Stand on the left, beside the jointer, not behind or in line with your material. You will have more control over your material, will not have to reach so far, and will not be hit by the material if it is thrown from the machine. 11. Shift your hands so they never pass over the knife head at any time.

What can I use instead of a jointer?

If you don't have one, and one isn't available to you, you can make a router sled and use that to flatten both faces of your board, then a different technique to edge joint them. Last but not least, this will hold true for all the techniques mentioned, you can always use hand tools!

Will a planer fix warped boards?

In order to flatten a warped, twisted, or cupped board, a common approach is to first use a jointer to create one perfectly flat face. Then you run the board through a thickness planer with the flat face downward, and the planer makes the top face parallel to the bottom.

How long should a jointer plane be?

Jointer planes are typically 20 to 24 inches (510 to 610 mm) long, and are the longest hand planes commonly used. Under the Stanley Bailey numbering system #7 and #8 planes are jointer planes.

Can you joint with a table saw?

Using Your Table Saw as a Jointer. Even if you own a jointer, you'll want to master this technique. With the addition of a simple shop-made fence, you can easily edge joint on your table saw. Remember that man-made materials like plywood can be hard on steel jointer knives – but not on carbide table saw blades.

Does a jointer straighten boards?

Wood Jointer—The Easy Way to Make Square and Flat Board Surfaces. ... A jointer quickly smooths and flattens the edge of a board while cutting it square to an adjacent edge. Once this is done, the board is ready to lie flat against a table saw fence or table for a straight cut.

What is a jointer vs planer?

A jointer creates a flat surface on wood, and yes, it can be used to correct bow and warp on one side of a board at a time. "A planer is a thicknesser. It takes a thick board and makes it thinner. ... At the same time, the planer will also make the rough side both smooth, and parallel to the other side.

Can you Joint 4 sides of a board?

You can make all 4 sides square with opposite sides parallel with a hand plane. The best way to understand why you cannot do it with a jointer is first learn the steps necessary to do it by hand.

Who invented the jointer?

As covered in Early History of Jointers, the modern jointer was patented by Climer and Riley in 1866. Before that, many attempts were made to produce an effective machine to flatten the faces of boards. The earliest woodworking machines were sawmills that reduced a log to rough-sawn boards.

How much does a jointer take off?

Again, the maximum cut will depend on the width and density of the workpiece, but I generally don't remove more than about 1⁄8" at a time. For pieces that aren't much longer than your infeed table, hook your heeled pushblock onto the trailing end of the board.
