Installing roof drip edge flashing properly The best way is to install the roof drip edge only along the eaves first, then place ice-and-water barrier (in the snowbelt) or felt paperfelt paper Common grades include 10-, 20-, 30-, and 60-minute. The higher the rating, the heavier and more moisture-resistant the paper. A typical 20-minute paper will weigh about 3.3 lbs per square, a 30-minute paper 3.75, and a 60-minute paper about 6. › wiki › Tar_paper

Tar paper - Wikipedia

(underlayment) over the drip edge. This lets any water that gets on the roof run down the underlayment and over the drip edge.

Does drip edge go over or under felt?

Does Drip Edge Go Over or Under Felt? According to most building codes and manufacturer recommendations, the drip edge should be installed beneath the underlayment along the eaves of the roof.

Does Ice and water Shield go over felt?

Ice and water protector membrane is a superior choice over roof felt for leak protection when properly installed and paired with the right products. Ice and water protector is part of a system working together to protect your roof, including the shingles and other underlayments.

Should shingles overhang the drip edge?

Yes. Shingles should not extend more than 3/4” (19 mm) past the drip edge. If shingles overhang the edge of the roof by more than 3/4” (19 mm), then they are not supported and may crack and break off.

Should drip edge be tight to fascia?

A vertical drip edge lip extends down roughly 1 5/8" and as Steve points out, should not be set tight against the fascia board or water may run behind the gutter and down the fascia, inviting leaks and rot.

Roofing - Does Drip Edge go Under or Over Underlayment or Tarpaper at the Roof Eave

17 related questions found

Does drip edge go on before fascia?

The correct placement of a roof drip edge is on top of the roof's exterior cover directly between the sheathing and the fascia board, which forms a drainage gap between the drip edge and the fascia board. As a result, the drainage improves water flow and protects the roof from potential water damage.

Where does drip edge go?

The drip edge should be installed on top of the underlayment at all rakes, and below or on top of the underlayment at the eaves. At the eaves, when installing the drip edge on top the underlayment, a 4-inch wide layer of asphalt roof cement (complying with the ASTM D4586, Type I or Type II) is required.

Should I put ice and water shield on my entire roof?

You may apply an ice and water protector on your entire roof, but this can also be costly overall. Instead, install it first on critical areas of your roof before you consider covering the whole roof. Install your ice and water protector covering at least 3 feet from the edge of your roof.

What is roofing drip edge?

Drip edge is metal flashing installed at the edges of the roof to keep water away from your fascia and from getting underneath your roofing components. If your roof doesn't have drip edge, water gets behind your gutters and rots out both your fascia board and roof decking.

Is a drip edge necessary on a roof?

Without a drip edge, water may end up beneath the shingles and may cause damage to various parts of the home. Though your home may not have originally had a drip edge installed, drip edges are now required by most building codes across North America to protect homes from damage.

Does drip edge go over gutters?

It is recommended that gutters are placed under or 'behind' the drip edge of your roof. ... If gutters are installed below the drip edge, water can drip behind the gutter and cause damage to the wood supporting the gutter system.

Which side of roofing felt goes down?

Direction. When laying sheets of tar paper, always lay the sticky, glossy side down. Tar paper's two sides are noticeably different. One side is somewhat sticky, though don't expect it to leave a glue-like residue on your hands.

What is the proper overhang for roof shingles?

The edge of the shingles should hang over a roof between an inch and an inch and a half — or between a half inch and three-quarters of an inch if drip edge flashing is installed. Too much overhang and the shingles could blow off in high winds; too little can allow water to seep into rake or fascia boards.

Does drip edge go on rakes and eaves?

A drip edge should be installed on the eaves and rakes of the roof, flush with the decking and fascia. On eaves, the drip edge is installed directly to the deck with underlayment installed over it for proper water shedding. On rakes, the underlayment is installed over the drip edge.

Do you nail ice and water shield?

When nails penetrate the ice and water shield on the roof, the rubberized nature of the material creates a gasket effect on the shaft of the nail. Leaks simply don't happen. Not only does ice and water shield stop leaks caused by ice dams, but it also stops leaks created by fierce wind-driven rain.

How long does ice and water shield last on a roof?

The original, fully-adhered roofing underlayment, Grace Ice & Water Shield®, now has an extended exposure limit of 90 days. For more than 35 years, Grace Ice & Water Shield® has been the brand that roofing contractors and architects trust most to specify and install on marquee projects around the world.

Is ice and water shield a vapor barrier?

GRACE ICE & WATER SHIELD® membrane is an air and vapor barrier. Repair holes, fishmouths, tears, and damage to membrane with a round patch of membrane extending past the damaged area 6 in. (150 mm) in all directions. If fasteners are removed leaving holes in the membrane, they must be patched.

Can you install drip edge after shingles?

Can Drip Edge Be Installed After Shingles? The most popular time to install a drip edge is when new shingles are installed. However, the drip edge can be installed at any time. The materials involved include: a ladder, a flat pry bar, a hammer, tin snips, eave stripping, and galvanized roofing nails.

Why is water dripping between gutter and fascia?

If water is dripping behind your gutter, it's probably because it was installed without any flashing over the back of the gutter. The gutter apron will prevent the dripping. A gutter apron is a bent piece of flashing that tucks up under the shingles and over the gutter. Home centers sell a gutter apron in 10-ft.

How far do you overlap roofing felt?

Remember to leave a 2" overlap. Drive about five nails in the top right-hand corner and roll out the felt about halfway (perhaps 25 feet) across the roof. Stand on the first course of felt and work with the second course of felt above you. It is not necessary to completely nail the top edge of the course.

Do you nail or staple roofing felt?

Some roofers prefer to attach felt underlayment with 1-inch roofing nails or special nails with plastic washers, but most codes allow staples, which are easier to drive.
